GENERAL CHARACTERISTICS
Everwatt Ceramic Infrared bulbs are suitably designed for getting the highest performances and infrared waves emissions. Most of these items are available on stock.
Primarily these ceramic infrared bulbs are used in the area og reptile/animal health care. Consisting og a high temperature Iron/Chromium aluminised (FeCrAl) resistance alloy embedded in a ceramic body temperature resistant up to 530 C° and a maximum power of 400W. The bulb face can either have a circular or convex design, whose shape does suitably allow to produce a circular outward trending infrared radiant output.
Technical features
- Surface temperature (skin): 300 ° C (60W) 426 ° C (100W) 441 ° C (150W) 516 ° C (250W) 450 ° C (300W) 530 ° C (400W)
- Max Watts density: 7.3kW / m² (60W) 13.5kW / m² (60W) | 12kW / m² (100W) | 22.5kW / m² (100W) | 15kW / m² (150W) | 25kW / m² (250W) | 22.5kW / m² (300W) | 30kW / m² (400W)
- Sizes: Ø65×140 mm | Ø80×110 mm | Ø95×140 mm | Ø140×137 mm
- Color: White / Yellow / Black
- Power: 60W | 100W | 150W | 250W | 300W | 400W
- Resistore wire FeCrAl
- Supplied Voltage: 230 ~ 240V standard (other voltages available on request)
- Mean useful wavelength (range): 2-10 μm
- Average operating life: 5.000 – 10.000 h
- Recommended infrared waves radiation distance between the heating source and the object / body heat up: 100 – 200 mm
- Threaded plug type E27 Edison
- Average weight (range): 113g to 253g
- Certification: UL
SOME EXAMPLES:
