DESCRIPTION
The Silicone, PVC and glass fibre heating cables are designed to be extremely flexible and suitable for the most different applications.
These cables are made by wrapping the resistive wire on a core made of material resistant to high temperatures, insulating the assembly by silicone, PVC and glass fibre.
The wire can be protected by an additional jumper consisting of interlaced wires in (tinned) copper AISI 304 and glass fibre; this is done to increase sturdiness, making it suitable for high risk environments.
The electric resistors with heating wire boast flexible components adapting optimally to the surfaces to be heated, with which they come into direct contact and it grants excellent insulation values, even in immersion operation or anyhow in high relative humidity environment.
In addition, they allow to dose and differentiate the heat according to specific needs, being able to calibrate different specific
powers.
Technical characteristics
The heating cables are supplied in reel or alternatively, they can be cut in sections, according to the client’s specific needs.
Resistance values obtainable: Max. 20,000 ohm/m – Min. 10 ohm/m
Main claddings used: Silicone rubber, glass fibre, Silicone + glass fibre
By protecting the heating cable by a jumper/metallic plate and a sheath, it is also possible to prevent possible damages to the insulator.
Some uses suggested
All the heating cables types adapt to multiple uses, some of them in particularly important and demanding sectors, among which:
OTHER USES:
Antifrosting heating cable: an alternative but effective use of the heating cables is to prevent the condensation formation inside freezers and industrial and non-industrial refrigeration devices such as cold rooms, cold stands, refrigerated display cases, etc…
Defrosting heating cable in discharge channels, preventing the ice formation
CERTIFIED QUALITY PRODUCT
The heating cables entire production cycle is subject to the strictest dimensional checks and electric tests in compliance with the standards set forth by our own ISO 9001:2015 certified Corporate Quality System, and in full compliance with the CEI/EN requirements in force.
STANDARD RESISTORS INCLUDED IN THE CATALOGUE
This heaters typology can be manufactured upon client’s specifications and also in standard version, whose we have a prompt delivery warehouse, for wire section, power, and standard voltage.
SOME EXAMPLES:
